G657A2 OM3 96 Core MM APC/UPC To MTP/MPO MPO Fiber Optic Cable Multi Mode FTTH Yellow
Product Description of OM3 MPO/MTP Cable:
MTP fiber patch connectors make use of precision-molded MT ferrules with metal guide pins and precise housing dimensions to ensure fiber alignment when mating. MTP fiber cable can be mass terminated in combinations of 4, 8, 12, 24, 48, and 96 fiber ribbon cables and are typically used in high-density backplane and Printed Circuit Board (PCB) applications within data and telecommunications systems.
MPO (Multi-Fiber Push-on) is the first generation of clip-clamping multi-core optical fiber connectors. MTP/MPO cables are composed of MTP/MPO connectors and optical fibers. MTP/MPO connectors have a female type (without pins) or a male one (with pins). And a white dot is for identifying fiber position in connectors. MTP/MPO connectors largely increase the cable density and save circuit card and rack space, which are well suited for current 40G/100G cabling and future network speed upgrades.
The MTP trunk cable, a cost-effective alternative to time-consuming field termination, is designed for high-density fiber
Features of OM3 MPO/MTP Cable:
* Trunk Cable Counts usually 12 / 24 / 36 / 48 / 72 /96 / 144-fibers
* Backbone installation
* 100% tested before delivery
* MTP And MPO available
* Use 12/24 Cores Fiber Connector
* 3.0/3.6 mm Round Cable or Customized
* SM/OM1/OM2/OM3/OM4 or Customized
* LSZH, OFNR, and OFNP available
* Compliance with Telcordia GR-1435-Core Compliant
Applications of OM3 MPO/MTP Cable:
* MPO/MTP cassette
* LANs and WANs
* FTTx
* Military industry
* Data Centre Infrastructures
* Wiring of local area network between different enterprise buildings
* Connection of optical links in optical active devices
* Medical
* Telecom system
* Data Center
* High-Density Cabling Solution
* Connection of indoor to outdoor optical cable wiring equipment
* For internal connection applications of optical transceivers, 40G/100G QSFP, QSFP+, and other optical transceivers.
Details of MPO/MTP Cable:
| Performance Level | Standard Loss | Low Loss |
| Connector | Mode | Endface | IL(max) (dB) | RL(min) (dB) | IL(max) (dB) | RL(min) (dB) |
| MPO/MTP | SM | 12F/APC | ≤0.70 | ≥60 | ≤0.35 | ≥60 |
| 24F/APC | ≤0.75 | ≥60 | ≤0.35 | ≥60 |
| 48F/APC | ≤0.75 | ≥60 | | |
| MM | 12F/PC | ≤0.50 | ≥20 | ≤0.35 | ≥20 |
| 24F/PC | ≤0.50 | ≥20 | ≤0.35 | ≥20 |
| 48F/PC | ≤0.50 | ≥20 | | |
OEM and ODM:
OEM/ODM order is available:
We can supply products according to your requirements, and design products label for your company.
Shipment:
International Express: DHL, FedEx, EMS, TNT, UPS, and so on. It takes 1-5 days.
Guarantee:
We promise all the advertised optical transceivers are brand new with new components and parts and absolutely never use old and refurbished materials. All the optical transceivers have been through functional tests and aging tests. We provide 3 years warranty for all-optical transceivers from the date of shipment.
